TP-LINK TL-SG1210MPE 10 Port Smart Switch with 8-Port PoE+
Part Number: TL-SG1210MPE
Discontinued
This product has been discontinued.
The TP-Link TL-SG1210MPE is an easy smart unmanaged network switch with 10 Gigabit RJ45 ports, 8 of which support PoE+ delivering up to 30W each. Featuring an intuitive plug-and-play design requiring no configuration, the TL-SG1210MPE can provide both power and network connectivity to power-hungry devices such as access points, IP cameras or VoIP phones, and is well-positioned to function as the backbone of a home office or small business's networking infrastructure.
Description
The TL-SG1210MPE includes 10 gigabit RJ45 ports, one of which can also function as a high-speed SFP uplink, for an aggregate non-blocking switching capacity of 20Gbps. Despite its ease of setup, the switch is also capable of providing advanced network security and diagnostics features like network monitoring, traffic prioritisation and VLANs.
Of the TL-SG1210MPE's 10 RJ45 ports, 8 can provide 30W of 802.3af/at PoE+ (up to a maximum of 123W) to connected devices, expanding the possibilities of network infrastructure deployment to locations where there may be insufficient power outlets. The TL-SG1210MPE is also equipped with PoE Auto Recovery, a protocol whereby the switch can automatically detect if a connected device has lost network connectivity or become unresponsive and force a reboot.
The unit is encased in a robust metal chassis ensuring operational longevity, and has been engineered to operate silently owing to its fanless design.
Key Highlights
- Layer 2 unmanaged smart switch
- 10 x RJ45 ports
- 8 x PoE+ ports
- 10 x Gigabit RJ45 ports
- 1 x 1G SFP port
- Total available PoE: 123W
- Max. PoE wattage per port: 30W
- Switching Capacity: 20 Gbps
- PoE auto-recovery
- Automatic power management for overvoltage protection
- Network monitoring
- VLAN support
- Fanless design for silent operation
What’s in the box?
- 1 x TL-SG1210MPE
- 4 x Rubber Feet
- 1 x UK Power Adapter
- 1 x Quick Start Guide
Specification
| Supports Gigabit | 1 |
|---|---|
| Supports PoE | 1 |
| Gigabit Ports | 10 |
| PoE Ports | 8 |
| RJ45 Ports | 10 |
| SFP Ports | 1 |
| Managed | 0 |
Documents
Data Sheet:TL-SG1210MPE Data Sheet
