Shelly Pro Sensor Add-On
Part Number: SHELLY-PRO-SENSOR-ADD-ON
Out of stock
Bulk Pricing
1+
£39.99
5+
£38.62
10+
£37.24
Transform your Shelly Pro devices into a powerful sensor hub with the Shelly Pro Sensor Add-on. This galvanically isolated interface allows you to connect multiple analogue, digital, and 1-Wire sensors for real-time monitoring and advanced automation, offering maximum flexibility for residential and commercial environments.
Description
The Shelly Pro Sensor Add-on is a galvanically isolated interface designed to expand the capabilities of your Shelly Pro series devices. By acting as a versatile sensor hub, it enables real-time environmental monitoring and advanced automation across residential, commercial, and industrial settings.
Equipped with multiple input and output options, this add-on allows you to integrate a wide range of third-party sensors, including those compatible with Arduino. It features two 1-Wire data terminals, two analogue inputs (0-10V), two digital inputs (±15V), and a potential-free solid-state relay output for direct control of external circuits.
Common use cases include:
- Optimising HVAC systems by monitoring temperature and humidity.
- Automating lighting through connected motion detectors.
- Protecting property with water leak and wind sensors.
- Managing smart irrigation based on soil moisture levels.
- Monitoring server rooms or critical infrastructure.
Key Highlights
- Galvanically isolated interface
- Two 1-Wire data terminals
- Two analogue inputs (0-10V)
- Two digital inputs (±15V)
- One potential-free solid-state relay output
- DIN rail mountable
- Compatible with Arduino sensors
- Powered directly by Shelly Pro devices
