Aruba Instant On 1830 JL810A 8-Port Smart Managed Switch
Part Number: JL810A-ACC
Out of stock
This product is out of stock. Please call on 0330 043 3000 to confirm availability.
Bulk Pricing
1+
£98.49
5+
£95.25
10+
£92.00
The Aruba Instant On JL810A is a smart-managed Layer 2 Ethernet 8-port Switch from the 1830 series. The JL810A switch provides an easy to use and affordable wired solution for networks supporting IT, mobile, and cloud applications.
Description
The Aruba JL810A is an easy-to-deploy, smart-managed switch that is ideal for small businesses looking for cost-effective wired infrastructure to keep up with evolving network demands. It can be powered by an upstream Power over Ethernet (PoE) switch for environments where no line power is available.
The JL810A offers Layer 2 switching capabilities, Gigabit connectivity, along with flexible management modes. With a flexible management dashboard and energy-efficient features, it can deliver a solid business network for SMBs with limited budgets.
The Aruba Instant On 1830 Switch Series can be deployed using two management modes - Instant On cloud-management (access via mobile app and/or web portal) and the local web GUI.
The 1830 switches are enhanced with security features such as IEEE 802.1x, Global Storm Control, TPM (Trusted Platform module) based security, and VLANs to guard your network from unwanted or unauthorised access. Leverage 802.1X with a RADIUS server to verify only known and authorised users can access your network.
This JL810A has Energy Efficient Ethernet (EEE), and is compliant with 802.3az standard requirements to save energy during periods of low data activity.
This switch supports table-top mounting and wall mounting with ports facing either up or down. It also supports under-table mounting using base surface mounting holes. Please note, this switch does not support rack mounting options.
For further information about Aruba's range of switches and access points, please see our blog!
Key Highlights
- 8 x RJ-45 autosensing 10/100/1000 ports
- Memory & Flash: ARM Cortex-A9 @ 800MHz, 512 MB SDRAM, 256 MB flash
- Packet Buffer: 1.5MB
- Throughput (Mpps): 11.90 Mpps
- Capacity: 16 Gbps
- MAC address table size (number of entries): 8,000 entries
- Fanless design
- Frequency: 50Hz/60Hz
- AC voltage: 100-127VAC / 200-240VAC
- Current: 12V -- 1.0A
- Maximum power rating: 100-127V: 8.09W 200-220V: 8.05W
- Power supply: External power adapter (included)
- Device management: Aruba Instant On Cloud; Web browser; SNMP Manager
- Product Dimensions (DxWxH): 157mm x 173mm x 39.1mm mm
- Weight: 0.77 kg; 1.70 lb
What’s in the box?
- Aruba Instant On 1830 JL810A 8G Switch
- 4 x rubber feet
- 1 x tie strap
- 3 x screws (M4, 16T, 20mm)
- 3 x anchors
- Power cord
- Quick Start Guide
